Embedding a map image in an AutoCAD drawing using .NET

In this recent post we saw how to set our geographic location inside an AutoCAD drawing – essentially geo-referencing the model it contains – programmatically.

In today’s post we’re going to capture a section of the displayed map and embed it inside the drawing, much as the GEOMAPIMAGE command does. In fact, we’re going to use the GEOMAPIMAGE command to do most of the heavy lifting: we’ll simply call the command and then pick up the created GeomapImage object to manipulate its settings, adjusting some image properties (brightness, contrast and fade settings) and having the map image display hybrid (aerial + road) information.

Here’s the C# code implementing the CGI command, which should be run after the IGR command we implemented last time:

using Autodesk.AutoCAD.ApplicationServices;
using Autodesk.AutoCAD.DatabaseServices;
using Autodesk.AutoCAD.EditorInput;
using Autodesk.AutoCAD.Geometry;
using Autodesk.AutoCAD.Runtime;

namespace GeoLocationAPI
{
  public class Commands
  {
    [CommandMethod("CGI")]
    public void CreateGeoMapImage()
    {
      var doc = Application.DocumentManager.MdiActiveDocument;
      if (doc == null)
        return;
      var ed = doc.Editor;
      var db = doc.Database;

      // Get the first corner of our area to convert to a
      // GeomapImage

      var ppo = new PromptPointOptions("\nSpecify first corner");
      var ppr = ed.GetPoint(ppo);
      if (ppr.Status != PromptStatus.OK)
        return;

      var first = ppr.Value;

      // And get the second point as a corner (to rubber-band
      // the selection)

      var pco =
        new PromptCornerOptions("\nSpecify second corner", first);
      ppr = ed.GetCorner(pco);

      if (ppr.Status != PromptStatus.OK)
        return;

      var second = ppr.Value;

      // We'll use an event handler on the Database to check for
      // GeomapImage entities being added
      // (we'll use a lambda but assigned to a variable to be
      // able to remove it, afterwards)

      ObjectId giId = ObjectId.Null;
      ObjectEventHandler handler =
        (s, e) =>
        {
          if (e.DBObject is GeomapImage)
          {
            giId = e.DBObject.ObjectId;
          }
        };

      // Simply call the GEOMAPIMAGE command with the two points

      db.ObjectAppended += handler;
      ed.Command("_.GEOMAPIMAGE", first, second);
      db.ObjectAppended -= handler;

      // Only continue if we've collected a valid ObjectId

      if (giId == ObjectId.Null)
        return;

      // Open the entity and change some values

      try
      {
        using (var tr = doc.TransactionManager.StartTransaction())
        {
          // Get each object and check if it's a GeomapImage

          var gi =
            tr.GetObject(giId, OpenMode.ForWrite) as GeomapImage;
          if (gi != null)
          {
            // Let's adjust the brightmess/contrast/fade of the
            // GeomapImage

            gi.Brightness = 90;
            gi.Contrast = 40;
            gi.Fade = 20;

            // And make sure it's at the right resolution and
            // shows both aerial and road information

            gi.Resolution = GeomapResolution.Optimal;
            gi.MapType = GeomapType.Hybrid;

            gi.UpdateMapImage(true);
          }

          tr.Commit();
        }
      }
      catch (Autodesk.AutoCAD.Runtime.Exception)
      {
        ed.WriteMessage(
          "\nUnable to update geomap image entity." +
          "\nPlease check your internet connectivity and call " +
          "GEOMAPIMAGEUPDATE."
        );
      }
    }
  }
}
